Part number: EP1305 BLACK 50ML
Please contact your Ellsworth Customer Service Representative to confirm availability and delivery time.
ResinLab EP1305 Black is a two component, room temperature or heat curing, urethane epoxy that is used for bonding metal, ceramics, and PVC. It is thixotropic, non-sagging, and toughened. 50 mL Cartridge.
| Typical Use: | The system has a thixotropic non-sag viscosity but is easily dispensed from side-by-side cartridge systems. It was especially formulated to a 1A:1B mix ratio for use in automatic mixing equipment and dispensers with static mixers. |
| Chemical Composition: | Epoxy |
| Color: | Black |
| Components: | 2 part |
| Cure System: | Room Temperature/Heat |
| Cure Time: | 2 to 4h @ room temperature; 2h @ 65 °C; 1h @ 100 °C |
| Dielectric Strength: | 440 V/mil |
| Elongation: | 10% @ break |
| Flash Point: | >93.3 °C |
| Hardness: | 70 D |
| Mix Ratio: | 1:1 by volume; 1.15:1 by weight |
| Peel Strength: | 15 pli |
| Service Temperature: | -40 to 150 °C |
| Shear Strength: | 1,000 |
| Specific Gravity: | Mixed: 1.08 |
| Tensile Strength: | 3,500 psi |
| Viscosity: | Mixed: 109,000 |
| Volume Resistivity: | 2.1 x 10^15 ohm-cm |
-
