ResinLab EP965SC7 Epoxy Encapsulant Black 50 mL Cartridge

Part number: EP965SC7 BLACK 50ML
ResinLab EP965SC7 Epoxy Encapsulant Black 50 mL Cartridge
Quantity Price
1 $3,625.20 ($30.21 each) 3625.200000000 CAD New Limited Availability EP965SC7 BLACK 50ML
2 $3,366.00 ($28.05 each) 3366.000000000 CAD New Limited Availability EP965SC7 BLACK 50ML
3+ $3,154.80 ($26.29 each) 3154.800000000 CAD New Limited Availability EP965SC7 BLACK 50ML
Sold as a pack (120/pk).
Usually Ships in 2-3 Business Weeks. Subject to prior sales. Non-returnable product. Canceled orders may incur a fee at the supplier’s discretion. Product not sold online in Quebec.
  • J Haz Class 8

ResinLab EP965SC7 Black is a two component, room temperature or heat curing, unfilled epoxy encapsulant that is used for medium castings, bonding with most materials, and filling voids. It is electronic grade, semi-rigid, free flowing, and has good air release and wetting properties. It is resistant to bases, acids, water, and most organic solvents. 50 mL Cartridge.

ResinLab EP965SC7 Black is a two component, room temperature or heat curing, unfilled epoxy encapsulant that is used for medium castings, bonding with most materials, and filling voids. It is electronic grade, semi-rigid, free flowing, and has good air release and wetting properties. It is resistant to bases, acids, water, and most organic solvents. 50 mL Cartridge.
Typical Use: Designed for medium sized castings.
Chemical Composition: Epoxy
Color: Black
Components: 2 part
Cure System: Room Temperature/Heat
Cure Time: 24h @ room temperature; 1h @ 65 °C; 20min @ 110 °C
Dielectric Strength: 410 V/mil
Elongation: 3% to 6% @ break
Flash Point: Part A: 249 °C; Part B: >100 °C
Hardness: 80 D
Mix Ratio: 1:1 by volume; 100:85 by weight
Service Temperature: -40 to 150 °C
Specific Gravity: Mixed: 1.07
Tensile Strength: 7,500 psi
Thermal Conductivity: 0.14 W/mK
Viscosity: Mixed: 8,000
Volume Resistivity: 8 x 10^14 ohm-cm
Working Time: 45 to 60min
