ResinLab EP1282 Epoxy Encapsulant Part B Black 1 gal Pail

Part number: EP1282 BLACK - B GL Manufacturer SKU: EP1282 BLACK B GL
ResinLab EP1282 Epoxy Encapsulant Part B Black 1 gal Pail

Please contact your Ellsworth Customer Service Representative to confirm availability and delivery time.

Call Us

Call Us
Contact customer service at 888-458-0554.

Email Us

Email Us
Email our quotes team.

ResinLab EP1282 Black is a two component, room temperature or heat curing, unfilled, flame resistant, epoxy encapsulant that is used for medium castings. It offers good wetting, semi-rigid polymer, high gloss surface, good thermal shock and cycling properties. It is resistant to bases, acids, water, and most organic solvents. Part B, 1 gal Pail.

ResinLab EP1282 Black is a two component, room temperature or heat curing, unfilled, flame resistant, epoxy encapsulant that is used for medium castings. It offers good wetting, semi-rigid polymer, high gloss surface, good thermal shock and cycling properties. It is resistant to bases, acids, water, and most organic solvents. Part B, 1 gal Pail.
Typical Use: Designed for medium sized castings.
Chemical Composition: Epoxy
Color: Black
Components: 2 part
Cure System: Room Temperature/Heat
Cure Time: 24 to 48h @ 25 °C; 1h @ 65 °C; 20min @ 100 °C
Dielectric Strength: 770 V/mil
Elongation: 56%
Flash Point: >93 °C
Hardness: 65 D
Mix Ratio: 1:1 by volume; 1.17:1 by weight
Service Temperature: -40 to 150 °C
Shear Strength: 1,500
Specific Gravity: Part A: 1.14; Part B: 0.98; Mixed: 1.06
Tensile Strength: 2,400 psi
Thermal Conductivity: <0.2 W/mK
Viscosity: Part A: 7,500; Part B: 2,000; Mixed: 3,000
Volume Resistivity: 1.3 x 10^14 ohm-cm
Working Time: 1h
